Rotameters for Every Application
Variable area (VA) flow meters, or rotameters, are some of the oldest devices used for flow measurement, known for their flexibility across various applications and high reliability.
Yokogawa VA flow meters offer simple installation and trouble-free operation while delivering highly accurate flow measurements in low flow, high pressure, and other applications. Yokogawa’s rotameter series features various materials and designs including glass, plastic, and metal metering tubes as well as additional features suited for a range of mediums and applications.
Select the ideal rotameter for your process needs.
How Variable Area Flow Meters Work
VA flow meters consist of a cone, float, scale, and process connection. Operating under the variable area flow principle, rotameters use a simple design in which a float rises inside a conically shaped glass tube as the flow increases and its position on the scale gives the flow rate.
-
RAGN
The RAGN Rotameter is designed for continuous flow measurement of liquids and gases. The borosilicate glass metering tube has a brightly colored easy-to-read scale. In-line 316 stainless steel fittings are standard.
-
RAMC
- RAMC Variable Area Flow Meter
- Variable area principle
- Robust design
- Reliable measurement
- Gas, liquid, steam applications
-
RAKD
The RAKD Rotameter is used for measurement of liquids and gases and is highly accurate, particularly for low flows and high pressure applications.
-
RAGL
The RAGL rotameters are specifically designed for the measurement of low flows of liquid and gases. Their main application field is in purging, analyzer and gas sampling systems, laboratories and machinery equipment.
-
RAGK Short Rotameter
Thie Short Rotameter RAGK is designed for measurement of liquids and gases. The conical glass metering tube has a free rotating float. Measureable Flow Rate: Water = 0.002 l/h to 600 l/h; Air = 0.2 l/h to 6300 l/h
Details
The measurement technique is dependent on the density, viscosity and temperature of the medium. Exact results can be expected only if the characteristics of the medium remain constant. In the case of metal rotameters such as the RAMC, the special shape of the float results in less dependence on viscosity at lower viscosities.
Download our user-friendly Rotameter Sizing Program to build the correct rotameter for your application.
In the 1990s, Yokogawa strengthened its focus on flow meters through cooperation with and the eventual acquisition of the German flow meter manufacturer ROTA. As a result, Yokogawa gained access to 100 years of flow meter expertise and completed its flow meter portfolio by adding the Rotameter (variable area) and Rotamass (Coriolis) product lines.
Resources
With the increased interest in green energy and renewable fuel sources, Biodiesel has emerged as a viable alternative to standard petroleum based diesel and home heating oil. It has zero CO2 emissions and can be created from waste vegetable oil or rendered animal fat. The number of Biodiesel processing plants has grown to over 2500 in the US alone.
One of the most widely used methods of monitoring / controlling liquid level in a tank is the use of Bubble Tubes with Pressure or Differential Pressure Transmitters. A small but uninterrupted flow of air or inert gas is forced down through a dip tube which extends to near the bottom of the tank. The back pressure of the introduced gas is a function of the liquid level or head in the tank. The pressure transmitter takes the back pressure and converts it to an analog signal that is sent to the control room. The plant operator will then be able to monitor the exact level in the tank.
Ozone is recognized among the strongest, fastest, commercially available disinfectants and oxidants for water treatment, ozone is used in both the disinfection of drinking water and bacterial killer in wastewater treatment.
One of the major prohibitive factors for expanding solar power in the market place is the high cost. The primary cost drivers in solar cell marketing are materials and manufacturing processes. Most solar cells in use today use silicon as the semiconductor that enables the photoelectric effect within the solar cell. Silicon is abundant but also expensive and in high demand as the solar and electronics industries compete for global supplies. There is now a cost effective process in use to extract the pure silicon needed for solar cells using less energy and reduced cost. This process is called the Fluidized Bed Reactor.
View Efficient Plant Article
Downloads
Videos
Discover how Yokogawa’s Total Insight Flowmeters with Process Guard transform operational safety and efficiency. In this video, we highlight its advanced capabilities in monitoring, diagnostics, and proactive intervention to minimize risks and maximize uptime.
Our experts review the theory behind flow measurement technologies. Discuss common flow application challenges and evaluate the different technologies when selecting a flow meter. They also give examples of best installation practices for successful measurements.
To effectively control and optimize industrial processes, trusting measurements from flowmeters is vital.
