The EJA210E is a Flange-mount Liquid Level Transmitter. Featuring DPharp digital sensor technology, it offers the performance and device intelligence needed for greater process insight.
Details
EJA210E features include:
- ± 0.075% Accuracy
- ± 0.1% per 1 year Stability
- 120 msec Response Time
- Exida and TUV SIL2 / SIL3 Certified
- Signal Characterizer for the 4 to 20 mA output
- Local Parameter Setting (LPS)
Explore how the EJA210E can help you Boost your bottom line.
What Are the Benefits of Liquid Level Transmitters?
Plants run better with Yokogawa liquid level transmitters. At its heart, Yokogawa's Liquid Level Transmitter with DPharp digital sensor offers the performance and device intelligence needed to get greater insight into your process.
Digital Performance
Yokogawa's DPharp digital sensor offers twice the performance and stability of the competitor's analog sensors. The DPharp uses the latest in IC Chip-style design and manufacturing technology. Analog sensors are based on older design technology. Although analog sensors are good, the modern DPharp sensor out performs them.
Poor Performance = Lost Money
More Information
Yokogawa's DPharp sensor can supply you greater insight into your process. One transmitter can supply your control system with Tank Level (Primary Variable), Blanket Pressure (Secondary Variable), and Sensor Temperature (Third Variable) - no need for multiple devices.
More Information = Found Money
Signal Characterization
Signal characterization is a versatile function available on all Yokogawa pressure transmitters. The function is used to compensate the analog 4 to 20 mA output signal for non-linear applications. Such applications include tank strapping or flow measurements; but, it can be used in any application where the relationship between the pressure input and the desired output signal are known. This feature can use up to 10-points.
Greater Flexibility = Found Money
How to Reduce Total Cost of Ownership?
Routine maintenance is easier with Yokogawa liquid level transmitters. Efficient and effective maintenance through Extended Calibration Check Intervals, Standard Communication Protocols, and Multiple Communication Options.
Extended Calibration Check Intervals
Yokogawa EJA-E series pressure transmitters have a long-term stability of ±0.1% per 7 years under all operational conditions. As you gain experience with these transmitters, you will be able to extend the time between calibration checks. Long-term this can help reduce your maintenance cost by up to 33%. Spend your time where it is needed.
Quicker Maintenance = Less Downtime
Standard Communication Protocol
Yokogawa transmitters support all industry standard field device communication protocols. Interoperability and interchangeability can be ensured. Use all the same tools and work procedures as before. Yokogawa transmitters are available with analog 4 to 20mA signal with either BRAIN® digital protocol or HART® digital protocol; Low Power analog 1 to 5 VDC with HART® digital protocol; or all digital FOUNDATION® Fieldbus or PROFIBUS® PA protocol.
FieldMate HHC is a traditional hand-held communicator that allows you to communicate with transmitters in the field. If you forget your HHC, the LPS feature of your Yokogawa transmitter allows you to update 9 parameter without the HHC.
Quicker Maintenance = Less Downtime
Yokogawa liquid level transmitters help plants run longer.
Yokogawa's Inherently Safe Design, Proven Technology, and Rugged Construction allow users to run their plants safer and with less downtime.
Rugged Construction
Ruggedly constructed liquid level transmitter can help your plant reduce failures. Yokogawa's liquid level transmitters have construction features that are designed to allow it to outlive your plant. Four-bolt pressure retaining design, Teflon coated 316L stainless steel flange gasket, and dual seal certified to ANSI/ISA 12.27.01 - all design features to extend the life of the transmitter.
Ruggedness = Reliability
Proven Technology
Starting with a clean sheet of paper, Yokogawa developed in the early 1990s a completely new pressure sensing technology - the DPharp sensor. Yokogawa made a large commitment of resources and money in its development. That dedication paid off. Now there are over 9 million installed Yokogawa transmitters and calibrators worldwide using this technology.
Less Downtime = Making Product
Inherently Safe
All Yokogawa EJA-E series pressure transmitter are designed and certified to IEC61508:2010 Parts 1 through 7 and IEC61511:2004 Parts 1 through 3. They are certified for single transmitter use in SIL 2 rated safety applications and dual transmitter use in SIL 3 rated safety applications with no special option required. With Yokogawa EJA-E transmitters, no longer will you have to maintain two separate inventories - one for production applications and one for safety applications. How much will that save your company? The certificates are available under the "Download" tab above.
Inherently Safe = Reliability
For Yokogawa, safety should never be an option.
Capsule Ranges
| Capsule | Span | Range | Maximum Pressure Limit | ||
|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | ||
| M | 4.0 inH2O | 400.0 inH2O | -400.0 inH2O | +400.0 inH2O | per flange rating |
| H | 20.0 inH2O | 2,000.0 inH2O | -2,000.0 inH2O | +2,000.0 inH2O | |
Process Connections
| Process connection Type | Size | Extension | Flange | |
|---|---|---|---|---|
 |
Flush Type | 3-inch 2-inch 1 ½-inch |
N/A | JIS 10K, 20K |
| ANSI 150#, 300# | ||||
| JPI Class 150, 300 | ||||
| DIN PN10/16, 25/40 | ||||
 |
Extended Type | 4-inch 3-inch |
2-inch 4-inch 6-inch |
JIS 10K, 20K |
| ANSI 150#, 300# | ||||
| JPI Class 150, 300 | ||||
| DIN PN10/16, 25/40 |
Flushing Ring
A flushing ring a round device that is place between the diaphragm seal and the process connection. The device has two 1/4-inch ports that can be used to run a flushing solution across the face the seal to clean it. If you need a different size port, Yokogawa also offers Flushing Rings supplied by a global partner WIKA.
Communicators
Yokogawa manufactures a communicator for your needs. Yokogawa communicators are available for BRAIN Protocol, HART Protocol, FOUNDATION Fieldbus, PROFIBUS PA, ISA100, or Modbus. All out communicators are compatible with Yokogawa products as well as other products on the market.
Indicators
Yokogawa offers a range of loop powered and FOUNDATION Fieldbus remote indicators that can be used to locally monitor data from field instruments installed in difficult to access locations.
Resources
Download this eBook and learn:
- The basic physics of pressure
- Different types of pressure sensors
- Features of pressure transmitters
- Pressure transmitters communications standards
- Key characteristics of pressure
- Common types of diaphragm seals
Discover the safety features built-in to the Yokogawa digital pressure sensors (DPharp).
