挑战
客户面临的挑战
横河电机拥有构建控制和仪表解决方案的技术和经验,为寻求利用可再生能源的公司提供切实的利益。
发酵管理
挑战
必须根据每种原料调整控制温度的设定。
我们的解决方案
对于发酵管理,横河电机能够从各种预先设定中选择原料的理想温度控制设定。
批量和连续过程的集成管理
挑战
生产操作效率依赖于批量和连续过程,必须保持操作顺序的一致性才能提高生产操作效率。
我们的解决方案
横河电机的综合生产控制系统,批量和连续过程的操作方法是相同的。
直观的人机界面还可以帮助操作员更有效地工作。
高效装载
挑战
装载之前需要彻底检查所有产品的质量,然后有效地进行油库和卡车装载操作。
我们的解决方案
横河电机通过将油箱计量和卡车装载系统与CENTUM集成生产控制系统连接在一起,实现了集成管理。此外,在线气相色谱测量解决方案可以确保质量控制。
使能技术
CENTUM VP综合生产控制系统
CENTUM VP综合生产控制系统可确保“正常运行时间”不中断的工厂性能,从而在可再生能源领域实现较高的生产率和利润率。
Prosafe-RS
横河提供从固态和硬接线类型到DCS-SIS集成类型的完整安全仪表系统的产品线,涵盖化工行业的所有安全完整性等级(SIL 1至4)。
基于网路的控制系统STARDOM
STARDOM混合了PLC /智能RTU,提供双冗余和低功耗配置。STARDOM支持HART、Modbus、FOUNDATION™现场总线、以及其他网络协议。
FAST/TOOLS SCADA
FAST/TOOLS软件包能够优化可再生能源装置的性能。确保了高可用性和高性能,并支持在线组态。
YTA系列温度变送器
YTA系列温度变送器将传感器输入信号转换为4至20 mA、HART或FOUNDATION™现场总线信号;这消除了传统温度仪表经常遇到的导线电阻和信号噪声的缺点。
GC8000工业气相色谱仪
GC8000为工业气相色谱仪设定了新标准。它拥有多个恒温炉,大大扩展了功能。从12英寸彩色触摸屏的人机界面到强大的预测诊断功能,GC8000还带来了许多其他重要创新。
详细介绍
生物乙醇工艺
从农作物(原料)生产生物乙醇的过程,大致分为以下几个步骤:培养、发酵、蒸馏、脱水、储存和装载。首先,将原料放入到制备罐中,在这里用温水稀释。然后,将其放入发酵罐中,将糖浆和酵母混合拌入原料,以发酵原料中的糖。将发酵的糊状物移至调节塔中以增加乙醇浓度,之后移至蒸馏塔中,其中乙醇含量增加至体积的95%。进入脱水流程除水,使乙醇含量至少达到99.5%(体积百分比),以便乙醇作为燃料添加剂使用。
流程:
培养发酵
- 酵母罐/发酵罐温度控制
- 发酵管理
- 清洗管理
- 发酵液含糖量测定
蒸馏和脱水
蒸馏
- 输入流量控制
- 排放流量控制
- 回流流量控制
- 罐水平控制
- 底部液位控制
- 塔温度控制
脱水
- 脱水操作管理
存储和装载
- 卡车装载控制
- 罐库存管理
- 湿度测量
- 杂质测量(例如甲醇)
控制和测量技术
信息
- 操作支持
- 操作培训
- 工厂资产管理:
控制
- 综合监测和控制
- 安全仪表
测量
- 流量
- 压力
- 液位
- 温度
- pH
- 电导率
参考
